Valves weight chart in kg, mm, PDF delivers essential specifications for critical industrial operations. Professional engineers and purchasing managers rely on comprehensive weight data covering gate valves, ball valves, globe valves, and butterfly valves to optimize logistics planning, structural support calculations, and cost-effective procurement decisions.

Table of Contents

Comprehensive Weight Specifications for Industrial Valves – Complete Reference Guide

Detailed Weight Chart for Industrial Valves – Technical Specifications Database

Valve Type	Size (DN/mm)	Material	Weight (kg)	Flange Rating	End Connection	Actuator Weight (kg)	Total Weight (kg)	Application Category
Gate Valve	15	Carbon Steel	2.5	PN16	Flanged	0.8	3.3	Light Industrial
Gate Valve	20	Carbon Steel	3.2	PN16	Flanged	0.8	4.0	Process Control
Gate Valve	25	Carbon Steel	4.2	PN16	Flanged	1.2	5.4	Chemical Processing
Gate Valve	32	Carbon Steel	5.8	PN16	Flanged	1.2	7.0	Water Treatment
Gate Valve	40	Carbon Steel	6.9	PN16	Flanged	1.5	8.4	Municipal Systems
Gate Valve	50	Carbon Steel	8.7	PN16	Flanged	1.8	10.5	Chemical Processing
Gate Valve	65	Carbon Steel	11.4	PN25	Flanged	2.3	13.7	Industrial Process
Gate Valve	80	Carbon Steel	15.3	PN25	Flanged	2.8	18.1	Oil & Gas
Gate Valve	100	Carbon Steel	22.8	PN25	Flanged	3.5	26.3	Power Generation
Gate Valve	125	Carbon Steel	32.1	PN40	Flanged	4.2	36.3	Petrochemical
Gate Valve	150	Carbon Steel	45.6	PN40	Flanged	5.8	51.4	Heavy Industrial
Gate Valve	200	Carbon Steel	78.2	PN40	Flanged	8.5	86.7	Pipeline Systems
Gate Valve	250	Carbon Steel	125.4	PN63	Flanged	12.3	137.7	Major Infrastructure
Ball Valve	15	Stainless Steel	1.8	PN40	Threaded	0.5	2.3	Food Processing
Ball Valve	20	Stainless Steel	2.4	PN40	Threaded	0.5	2.9	Pharmaceutical
Ball Valve	25	Stainless Steel	3.1	PN40	Flanged	0.8	3.9	Dairy Industry
Ball Valve	32	Stainless Steel	4.2	PN63	Flanged	1.0	5.2	Chemical Plants
Ball Valve	40	Stainless Steel	5.1	PN63	Flanged	1.2	6.3	Marine Applications
Ball Valve	50	Stainless Steel	6.9	PN63	Flanged	1.5	8.4	High Purity Systems
Ball Valve	65	Stainless Steel	9.2	PN63	Flanged	2.0	11.2	Process Industries
Ball Valve	80	Stainless Steel	12.4	PN63	Flanged	2.5	14.9	Chemical Plants
Ball Valve	100	Stainless Steel	18.7	PN100	Flanged	3.2	21.9	High Pressure Systems
Ball Valve	125	Stainless Steel	26.8	PN100	Flanged	4.1	30.9	Critical Applications
Ball Valve	150	Stainless Steel	35.2	PN100	Flanged	5.5	40.7	Aerospace Industry
Globe Valve	15	Cast Iron	3.2	PN16	Threaded	0.6	3.8	HVAC Systems
Globe Valve	20	Cast Iron	4.1	PN16	Threaded	0.6	4.7	Building Services
Globe Valve	25	Cast Iron	5.8	PN16	Flanged	1.0	6.8	HVAC Systems
Globe Valve	32	Cast Iron	7.2	PN16	Flanged	1.2	8.4	Water Distribution
Globe Valve	40	Cast Iron	8.9	PN16	Flanged	1.4	10.3	Cooling Systems
Globe Valve	50	Cast Iron	11.5	PN16	Flanged	1.8	13.3	Water Treatment
Globe Valve	65	Cast Iron	15.2	PN25	Flanged	2.2	17.4	Steam Systems
Globe Valve	80	Cast Iron	19.8	PN25	Flanged	2.8	22.6	Municipal Water
Globe Valve	100	Cast Iron	28.3	PN25	Flanged	3.5	31.8	Building Services
Globe Valve	125	Cast Iron	38.7	PN40	Flanged	4.2	42.9	Industrial Steam
Butterfly Valve	50	Ductile Iron	6.8	PN16	Wafer	2.1	8.9	Water Systems
Butterfly Valve	65	Ductile Iron	8.4	PN16	Wafer	2.5	10.9	HVAC Applications
Butterfly Valve	80	Ductile Iron	10.7	PN16	Wafer	3.2	13.9	Fire Protection
Butterfly Valve	100	Ductile Iron	14.2	PN16	Wafer	4.1	18.3	Water Distribution
Butterfly Valve	125	Ductile Iron	18.5	PN16	Lug	5.2	23.7	Irrigation Systems
Butterfly Valve	150	Ductile Iron	21.7	PN16	Lug	6.8	28.5	Irrigation Systems
Butterfly Valve	200	Ductile Iron	32.4	PN25	Lug	9.5	41.9	Large Bore Applications
Butterfly Valve	250	Ductile Iron	45.8	PN25	Lug	12.8	58.6	Water Treatment Plants
Butterfly Valve	300	Ductile Iron	58.9	PN25	Lug	16.2	75.1	Industrial Cooling
Butterfly Valve	350	Ductile Iron	74.3	PN40	Flanged	20.1	94.4	Power Generation
Butterfly Valve	400	Ductile Iron	89.6	PN40	Flanged	24.8	114.4	Major Infrastructure
