Forged Pipe Weight Chart in kg, mm, and PDF specifications enable precise calculations for industrial piping systems requiring optimal design performance and structural integrity. These premium-grade forged pipe solutions utilize hot forging processes to enhance material strength, eliminate internal defects, and create seamless configurations with exceptional pressure resistance for high-stress applications in petrochemical, power generation, and offshore drilling environments, including high-pressure transmission lines, steam generation systems, boiler interconnections, refinery processing, corrosive media handling, and reactor system piping across diverse industrial sectors.
Essential Forged Pipe Weight Chart Specifications in kg and mm
Detailed Forged Pipe Weight Chart
Carbon Steel Forged Pipes (ASTM A105)
|
Nominal Size (inches) |
Outside Diameter (mm) |
Wall Thickness (mm) |
Weight per Meter (kg) |
Internal Diameter (mm) |
Cross-sectional Area (cm²) |
|
1/2 |
21.3 |
2.8 |
1.27 |
15.7 |
1.62 |
|
3/4 |
26.7 |
2.9 |
1.69 |
20.9 |
2.15 |
|
1 |
33.4 |
3.4 |
2.50 |
26.6 |
3.18 |
|
1-1/4 |
42.2 |
3.6 |
3.39 |
35.0 |
4.31 |
|
1-1/2 |
48.3 |
3.7 |
4.05 |
40.9 |
5.16 |
|
2 |
60.3 |
3.9 |
5.44 |
52.5 |
6.93 |
|
2-1/2 |
73.0 |
5.2 |
8.63 |
62.6 |
10.99 |
|
3 |
88.9 |
5.5 |
11.29 |
77.9 |
14.37 |
|
4 |
114.3 |
6.0 |
16.07 |
102.3 |
20.46 |
|
5 |
141.3 |
6.6 |
22.32 |
128.1 |
28.43 |
|
6 |
168.3 |
7.1 |
28.89 |
154.1 |
36.79 |
|
8 |
219.1 |
8.2 |
44.16 |
202.7 |
56.21 |
|
10 |
273.0 |
9.3 |
63.38 |
254.4 |
80.65 |
|
12 |
323.9 |
9.5 |
78.60 |
304.9 |
100.1 |
|
14 |
355.6 |
9.5 |
87.39 |
336.6 |
111.3 |
|
16 |
406.4 |
9.5 |
100.33 |
387.4 |
127.7 |
|
18 |
457.2 |
9.5 |
113.28 |
438.2 |
144.2 |
|
20 |
508.0 |
9.5 |
126.22 |
489.0 |
160.7 |
|
24 |
610.0 |
9.5 |
152.11 |
591.0 |
193.6 |
Stainless Steel Forged Pipes (ASTM A182 F316L)
|
Nominal Size (inches) |
Outside Diameter (mm) |
Wall Thickness (mm) |
Weight per Meter (kg) |
Internal Diameter (mm) |
Cross-sectional Area (cm²) |
|
1/2 |
21.3 |
2.8 |
1.42 |
15.7 |
1.81 |
|
3/4 |
26.7 |
2.9 |
1.89 |
20.9 |
2.40 |
|
1 |
33.4 |
3.4 |
2.79 |
26.6 |
3.55 |
|
1-1/4 |
42.2 |
3.6 |
3.78 |
35.0 |
4.81 |
|
1-1/2 |
48.3 |
3.7 |
4.52 |
40.9 |
5.76 |
|
2 |
60.3 |
3.9 |
6.07 |
52.5 |
7.73 |
|
2-1/2 |
73.0 |
5.2 |
9.62 |
62.6 |
12.26 |
|
3 |
88.9 |
5.5 |
12.59 |
77.9 |
16.04 |
|
4 |
114.3 |
6.0 |
17.92 |
102.3 |
22.83 |
|
5 |
141.3 |
6.6 |
24.89 |
128.1 |
31.72 |
|
6 |
168.3 |
7.1 |
32.22 |
154.1 |
41.06 |
|
8 |
219.1 |
8.2 |
49.24 |
202.7 |
62.71 |
|
10 |
273.0 |
9.3 |
70.68 |
254.4 |
90.01 |
|
12 |
323.9 |
9.5 |
87.68 |
304.9 |
111.7 |
Alloy Steel Forged Pipes (ASTM A182 F22)
|
Nominal Size (inches) |
Outside Diameter (mm) |
Wall Thickness (mm) |
Weight per Meter (kg) |
Internal Diameter (mm) |
Cross-sectional Area (cm²) |
|
2 |
60.3 |
3.9 |
5.67 |
52.5 |
7.22 |
|
3 |
88.9 |
5.5 |
11.76 |
77.9 |
14.98 |
|
4 |
114.3 |
6.0 |
16.74 |
102.3 |
21.32 |
|
6 |
168.3 |
7.1 |
30.11 |
154.1 |
38.34 |
|
8 |
219.1 |
8.2 |
46.02 |
202.7 |
58.63 |
|
10 |
273.0 |
9.3 |
66.05 |
254.4 |
84.15 |
|
12 |
323.9 |
9.5 |
81.91 |
304.9 |
104.4 |
