April 24, 2026Inconel Round Bars weight chart in kg, mm, pdf serves as the primary reference for industrial procurement. These austenitic nickel-chromium superalloys require precise weight calculations due to their varying diameters, lengths, and alloy compositions across different grades. Manufacturers and suppliers rely on standardized weight specifications to ensure accurate quotations and material planning in high-temperature applications.
Comprehensive Inconel Round Bars Weight Chart
Primary Weight Chart for Standard Inconel 600/601/625/718 Round Bars
|
Diameter (mm) |
Weight per Meter (kg) |
Cross-Sectional Area (mm²) |
Weight per 6m (kg) |
|
6 |
0.226 |
28.27 |
1.356 |
|
8 |
0.402 |
50.27 |
2.412 |
|
10 |
0.628 |
78.54 |
3.768 |
|
12 |
0.904 |
113.10 |
5.424 |
|
14 |
1.230 |
153.94 |
7.380 |
|
16 |
1.608 |
201.06 |
9.648 |
|
18 |
2.036 |
254.47 |
12.216 |
|
20 |
2.513 |
314.16 |
15.078 |
|
22 |
3.041 |
380.13 |
18.246 |
|
25 |
3.927 |
490.87 |
23.562 |
|
28 |
4.928 |
615.75 |
29.568 |
|
30 |
5.655 |
706.86 |
33.930 |
|
32 |
6.434 |
804.25 |
38.604 |
|
35 |
7.697 |
962.11 |
46.182 |
|
38 |
9.076 |
1134.11 |
54.456 |
|
40 |
10.053 |
1256.64 |
60.318 |
|
42 |
11.087 |
1385.44 |
66.522 |
|
45 |
12.733 |
1590.43 |
76.398 |
|
48 |
14.476 |
1809.56 |
86.856 |
|
50 |
15.708 |
1963.50 |
94.248 |
|
55 |
19.004 |
2375.83 |
114.024 |
|
60 |
22.619 |
2827.43 |
135.714 |
|
65 |
26.555 |
3318.31 |
159.330 |
|
70 |
30.786 |
3848.45 |
184.716 |
|
75 |
35.343 |
4417.86 |
212.058 |
|
80 |
40.210 |
5026.55 |
241.260 |
|
85 |
45.396 |
5674.50 |
272.376 |
|
90 |
50.893 |
6361.73 |
305.358 |
|
95 |
56.709 |
7088.22 |
340.254 |
|
100 |
62.832 |
7853.98 |
376.992 |
|
110 |
76.030 |
9503.32 |
456.180 |
|
120 |
90.478 |
11309.73 |
542.874 |
|
130 |
106.176 |
13273.23 |
637.056 |
|
140 |
123.124 |
15393.80 |
738.744 |
|
150 |
141.372 |
17671.46 |
848.232 |
|
160 |
160.849 |
20106.19 |
965.094 |
|
170 |
181.575 |
22698.01 |
1089.450 |
|
180 |
203.551 |
25446.90 |
1221.306 |
|
200 |
251.327 |
31415.93 |
1507.962 |
Inconel 625 Specific Weight Chart (Higher Density: 8.44 g/cm³)
|
Diameter (mm) |
Weight per Meter (kg) |
Weight per 3m (kg) |
Weight per 12m (kg) |
|
10 |
0.665 |
1.995 |
7.980 |
|
15 |
1.496 |
4.488 |
17.952 |
|
20 |
2.661 |
7.983 |
31.932 |
|
25 |
4.158 |
12.474 |
49.896 |
|
30 |
5.987 |
17.961 |
71.844 |
|
40 |
10.649 |
31.947 |
127.788 |
|
50 |
16.639 |
49.917 |
199.668 |
|
60 |
23.958 |
71.874 |
287.496 |
|
80 |
42.595 |
127.785 |
511.140 |
|
100 |
66.555 |
199.665 |
798.660 |
Inconel 718 Weight Chart for Aerospace Applications
|
Diameter (mm) |
Weight per Meter (kg) |
Surface Area per Meter (mm²) |
Volume per Meter (mm³) |
|
8 |
0.418 |
251.33 |
50265.48 |
|
12 |
0.940 |
377.00 |
113097.34 |
|
16 |
1.671 |
502.66 |
201061.93 |
|
20 |
2.612 |
628.32 |
314159.27 |
|
25 |
4.081 |
785.40 |
490873.85 |
|
32 |
6.683 |
1005.31 |
804247.72 |
|
40 |
10.442 |
1256.64 |
1256637.06 |
|
50 |
16.315 |
1570.80 |
1963495.41 |
Extended Weight Chart for Larger Diameters
Heavy-Duty Industrial Applications
For specialized industrial requirements, larger diameter Inconel round bars are available.
|
Diameter (mm) |
Weight per Meter (kg) |
Typical Applications |
|
220 |
304.335 |
Aerospace components |
|
250 |
393.270 |
Power generation |
|
280 |
492.816 |
Chemical processing |
|
300 |
565.486 |
Marine applications |
