How To Read A Fasteners Weight Chart In Kg, Mm, Pdf – Step By Step Guide

Fastener Type

Diameter (mm)

Length (mm)

Weight per Unit (g)

Weight – 1000 pcs (kg)

Material Grade

Phillips Head Screw

M4

16

1.8

1.80

Steel 4.6

Phillips Head Screw

M5

20

3.2

3.20

Steel 4.6

Phillips Head Screw

M6

25

5.1

5.10

Steel 4.6

Carriage Bolt

M8

30

11.4

11.40

Steel 4.6

Carriage Bolt

M10

40

18.7

18.70

Steel 4.6

Carriage Bolt

M12

50

28.9

28.90

Steel 4.6

Wing Nut

M6

–

3.4

3.40

Steel 4.6

Wing Nut

M8

–

6.8

6.80

Steel 4.6

Wing Nut

M10

–

12.5

12.50

Steel 4.6

T-Bolt

M8

35

14.2

14.20

Steel 8.8

T-Bolt

M10

45

23.6

23.60

Steel 8.8

T-Bolt

M12

55

36.8

36.80

Steel 8.8

Eye Bolt

M8

50

19.3

19.30

Steel 4.6

Eye Bolt

M10

60

31.7

31.70

Steel 4.6

Eye Bolt

M12

70

47.2

47.20

Steel 4.6

U-Bolt

M8

80×40

45.6

45.60

Steel 4.6

U-Bolt

M10

100×50

72.3

72.30

Steel 4.6

U-Bolt

M12

120×60

105.8

105.80

Steel 4.6

Lock Washer

M6

–

0.7

0.70

Spring Steel

Lock Washer

M8

–

1.3

1.30

Spring Steel

Lock Washer

M10

–

2.1

2.10

Spring Steel

Lock Washer

M12

–

3.2

3.20

Spring Steel

Thumb Screw

M6

20

4.9

4.90

Steel 4.6

Thumb Screw

M8

25

8.7

8.70

Steel 4.6

Thumb Screw

M10

30

14.5

14.50

Steel 4.6

Set Screw

M4

8

0.9

0.90

Steel 45H

Set Screw

M5

10

1.6

1.60

Steel 45H

Set Screw

M6

12

2.8

2.80

Steel 45H

Set Screw

M8

16

5.4

5.40

Steel 45H

Rivet

4.8

12

1.2

1.20

Aluminum

Rivet

6.4

16

2.8

2.80

Aluminum

Rivet

8.0

20

4.9

4.90

Aluminum
