The GI strip weight chart in kg, mm, PDF format provides crucial data for structural engineers and construction professionals. Accurate weight specifications enable precise load calculations and material planning across infrastructure, manufacturing, and fabrication projects.
Standard GI Strip Dimensions and Weight Reference
|
Thickness (mm) |
Width (mm) |
Length (m) |
Weight per Meter (kg) |
Weight per Bundle (kg) |
|
1.0 |
20 |
6 |
0.157 |
15.7 |
|
1.2 |
25 |
6 |
0.236 |
23.6 |
|
1.5 |
30 |
6 |
0.353 |
35.3 |
|
2.0 |
40 |
6 |
0.628 |
62.8 |
|
2.5 |
50 |
6 |
0.981 |
98.1 |
|
3.0 |
60 |
6 |
1.413 |
141.3 |
|
3.5 |
70 |
6 |
1.922 |
192.2 |
|
4.0 |
80 |
6 |
2.512 |
251.2 |
|
4.5 |
90 |
6 |
3.181 |
318.1 |
|
5.0 |
100 |
6 |
3.925 |
392.5 |
|
6.0 |
120 |
6 |
5.652 |
565.2 |
|
8.0 |
150 |
6 |
9.420 |
942.0 |
|
10.0 |
200 |
6 |
15.700 |
1570.0 |
Extended GI Strip Weight Specifications
|
Thickness (mm) |
Width Options (mm) |
Weight per m² (kg) |
Common Applications |
|
0.8 |
15, 20, 25 |
6.28 |
Electrical conduits, light frameworks |
|
1.0 |
20, 25, 30, 40 |
7.85 |
General fabrication, brackets |
|
1.2 |
25, 30, 40, 50 |
9.42 |
Structural supports, reinforcements |
|
1.6 |
30, 40, 50, 60 |
12.56 |
Heavy-duty brackets, frames |
|
2.0 |
40, 50, 60, 80 |
15.70 |
Industrial frameworks, supports |
|
2.5 |
50, 60, 80, 100 |
19.63 |
Construction reinforcements |
|
3.0 |
60, 80, 100, 120 |
23.55 |
Heavy structural applications |
|
4.0 |
80, 100, 120, 150 |
31.40 |
Industrial equipment frames |
|
5.0 |
100, 120, 150, 200 |
39.25 |
Heavy-duty structural components |
|
6.0 |
120, 150, 200, 250 |
47.10 |
Specialized industrial applications |
Comprehensive GI Strip Weight Chart in kg, mm, PDF Database
Galvanized iron strips serve as versatile structural components in construction, electrical installations, and manufacturing applications. The hot-dip galvanization process adds a protective zinc coating while marginally increasing overall weight specifications. Modern b2b portal systems have streamlined access to certified GI strip specifications and bulk procurement processes.
Understanding GI Strip Weight Calculations and Material Properties
GI strips combine the strength of steel with enhanced corrosion resistance through zinc coating. The galvanization process typically adds 2-4% to the base steel weight, depending on coating thickness and application requirements. Professional sourcing through established b2b portal platforms ensures compliance with international standards and consistent quality control.
Galvanization Impact on Weight Specifications
Zinc Coating Weight Contribution
The hot-dip galvanization process applies zinc coating ranging from 275-610 g/m², depending on application requirements. This protective layer adds approximately 0.2-0.5 kg per square meter to base steel weight, affecting total GI strip weight calculations.
Coating Thickness Variations
- Standard Coating (Z275): Minimum 275 g/m² zinc application
- Heavy Coating (Z450): Enhanced protection with 450 g/m² zinc layer
- Extra Heavy (Z610): Maximum corrosion protection at 610 g/m² coating
Material Grade Classifications
Commercial Quality GI Strip
Standard commercial grade offers optimal balance between formability and strength, suitable for general fabrication applications. These variants maintain consistent weight specifications across production batches.
Structural Quality GI Strip
Enhanced mechanical properties for load-bearing applications, with slightly increased weight due to higher carbon content and specialized alloying elements.
Digital Procurement and Specification Management
Modern B2B Portal Integration
Contemporary b2b portal systems revolutionize GI strip procurement by providing instant access to detailed specifications, real-time inventory, and automated weight calculations. These platforms integrate with project management systems for seamless material planning.
Advanced Calculation Software
Professional engineering platforms like pipex.ai integrate comprehensive GI strip databases with structural analysis tools, enabling real-time weight optimization and material selection. This technological advancement reduces calculation errors and improves project efficiency.
Application-Specific Weight Considerations
Construction Industry Requirements
Building construction demands precise GI strip weight calculations for structural load analysis and foundation design. Compliance with IS 1239 and ASTM A653 standards ensures consistent quality and predictable weight specifications.
Electrical Installation Applications
Electrical conduit systems require lightweight yet durable GI strip components. Weight optimization becomes critical for ceiling-mounted installations and cable management systems.
Manufacturing and Fabrication Uses
Industrial manufacturing processes benefit from standardized GI strip weight specifications for automated handling systems and precision assembly applications.
Quality Control and Weight Verification
Testing Standards Compliance
IS 2062, ASTM A36, and EN 10025 standards define dimensional tolerances and weight consistency requirements. Professional suppliers maintain rigorous quality control ensuring specification accuracy.
Digital Documentation Systems
Modern inventory management systems, including pipex.ai provide comprehensive tracking of gi strip specifications, enabling seamless integration with project documentation and compliance reporting processes.
Packaging and Transportation Considerations
Standard gi strip packaging involves bundling with steel strapping, adding approximately 2-3% to net product weight. Bulk transportation requires precise weight calculations for vehicle loading optimization and shipping cost management.
Conclusion
Comprehensive GIi strip weight chart in kg, mm, PDF documentation enables accurate engineering calculations and efficient material procurement strategies. Whether accessed through traditional catalogs or modern b2b portal platforms, precise weight specifications remain fundamental for successful project execution. The integration of digital tools continues to enhance accuracy and efficiency in structural material selection and optimization processes.
