Valves Weight Chart in Kg, Mm, Pdf is an accurate weight data that guarantees that each item fits and works according to plan, whether you’re choosing pipeline valves, figuring out load-bearing requirements, or organizing logistics. Engineers and project teams can meet industry standards and safety requirements while making quicker, more informed decisions with the help of comprehensive charts available in downloadable PDF format.
Gate Valves Weight Reference Chart
|
Nominal Size |
Inch Size |
Class 150 Weight (kg) |
Class 300 Weight (kg) |
Application Type |
|
DN50 |
2″ |
8.5 |
12.8 |
Standard/High-pressure |
|
DN80 |
3″ |
15.2 |
24.1 |
Medium-pressure/Critical systems |
|
DN100 |
4″ |
22.7 |
35.6 |
High-flow/Demanding environments |
|
DN150 |
6″ |
45.3 |
72.4 |
Large installations/Large-scale ops |
|
DN200 |
8″ |
68.9 |
125.3 |
Heavy-duty/Heavy industrial |
|
DN250 |
10″ |
98.4 |
185.7 |
Extra heavy-duty applications |
|
DN300 |
12″ |
142.6 |
268.9 |
Large-scale industrial systems |
Ball Valves Comprehensive Weight Data
Standard Ball Valve Specifications
|
Valve Size |
Floating Ball (kg) |
Trunnion Mounted (kg) |
Body Material |
Operating Pressure |
|
DN25 (1″) |
3.2 |
4.8 |
Carbon Steel |
150-300 PSI |
|
DN40 (1.5″) |
5.7 |
8.3 |
Carbon Steel |
150-300 PSI |
|
DN50 (2″) |
9.7 |
14.2 |
Carbon Steel |
150-600 PSI |
|
DN80 (3″) |
16.4 |
24.8 |
Carbon Steel |
150-600 PSI |
|
DN100 (4″) |
28.3 |
41.7 |
Carbon Steel |
150-900 PSI |
|
DN150 (6″) |
52.7 |
78.4 |
Carbon Steel |
150-900 PSI |
|
DN200 (8″) |
94.5 |
142.8 |
Carbon Steel |
150-1500 PSI |
|
DN250 (10″) |
148.2 |
224.6 |
Carbon Steel |
150-1500 PSI |
Check Valves Weight Specifications
|
Valve Size |
Swing Check (kg) |
Lift Check (kg) |
Dual Plate (kg) |
Material Grade |
|
DN50 (2″) |
7.8 |
6.4 |
5.2 |
ASTM A216 WCB |
|
DN80 (3″) |
13.6 |
11.8 |
9.4 |
ASTM A216 WCB |
|
DN100 (4″) |
19.7 |
17.2 |
14.8 |
ASTM A216 WCB |
|
DN150 (6″) |
38.9 |
34.5 |
28.7 |
ASTM A216 WCB |
|
DN200 (8″) |
62.4 |
58.1 |
47.3 |
ASTM A216 WCB |
