December 30, 2025Being a globally reliable single outer ring spiral wound gasket manufacturer, we lead the industry with precision-engineered sealing solutions. Our highly developed calculation utility allows customers to create a spiral wound gasket with an outer ring weight chart in the form of mm, kg, and PDF by customary input of the inner diameter of the gasket, the outer diameter of the gasket, the thickness of the gasket, and the density of the material used. This will remove manual calculations and maintain the correct results even concerning custom gasket requirements.
We also specialise in the production of a high variety of metallic gaskets, ring joint gaskets, and industrial sealing products, all of which comply with the stringent international performance and reliability requirements. Our products are designed to withstand tough pressure and temperature conditions; thus, they fit well in the critical applications in the oil and gas, petrochemical, power, and heavy engineering industries.
The Spiral Wound Gasket with Outer Ring Weight Chart offers quick, accurate and reliable weight predictions of different-sized gaskets and materials. It aids the engineers, fabricators and procurement personnel in choosing the right kind of gasket, enhancing cost control, minimising mistakes and maximizing the sealing performance of any project by providing precise information at the planning phase.
Spiral Wound Gasket with Outer Ring Weight Chart, Spiral Wound Gasket with Outer Ring Per Foot, Weight Of Spiral Wound Gasket with Outer Ring Per Meter, Spiral Wound Gasket with Outer Ring Weight Chart Pdf.
Spiral Wound Gasket with Outer Ring Weight Chart
|
316/FG/CS (weights in grams) |
||||||
|
DN |
150 |
300 |
600 |
900 |
1500 |
2500 |
|
1/2 |
31 |
40 |
40 |
62 |
62 |
78 |
|
3/4 |
41 |
61 |
61 |
70 |
70 |
87 |
|
1 |
51 |
69 |
69 |
87 |
87 |
106 |
|
1/4 |
51 |
79 |
79 |
98 |
98 |
155 |
|
1 1/2 |
79 |
100 |
100 |
113 |
113 |
190 |
|
2 |
100 |
121 |
121 |
291 |
291 |
293 |
|
2 1/2 |
139 |
169 |
169 |
367 |
367 |
387 |
|
3 |
115 |
200 |
100 |
304 |
375 |
500 |
|
4 |
239 |
269 |
269 |
444 |
500 |
682 |
|
5 |
200 |
365 |
578 |
635 |
705 |
955 |
|
6 |
220 |
485 |
661 |
882 |
851 |
1175 |
|
8 |
320 |
630 |
835 |
1420 |
1240 |
1715 |
|
10 |
445 |
770 |
1380 |
1926 |
1926 |
2606 |
|
12 |
800 |
975 |
1695 |
2669 |
2764 |
3363 |
|
14 |
1025 |
1628 |
1714 |
2336 |
3462 |
III |
|
16 |
1355 |
1720 |
2435 |
2569 |
4106 |
III |
|
18 |
1030 |
1887 |
2465 |
2985 |
4638 |
III |
|
20 |
1350 |
2215 |
3190 |
3444 |
5031 |
III |
|
24 |
1450 |
3370 |
3485 |
5000 |
7173 |
|
Spiral Wound Gasket with Inner and Outer Ring Weight Chart
|
316/FG/316/CS (weights in grams) |
|||||||
|
DN |
150 |
300 |
400 |
600 |
900 |
1500 |
2500 |
|
1/2 |
0,034 |
0,045 |
0,045 |
0,045 |
0.063 |
0,063 |
0,077 |
|
3/4 |
0,047 |
0,065 |
0,067 |
0,067 |
0,073 |
0,074 |
0.089 |
|
1 |
0,05 |
0,08 |
0,076 |
0,076 |
0,92 |
0,095 |
0.11 |
|
1/4 |
0,072 |
0,089 |
0,089 |
0.088 |
0,122 |
0,122 |
0,164 |
|
1/2 |
0.1 |
0,12 |
0,177 |
0,177 |
0,132 |
0,132 |
0,201 |
|
2 |
0.13 |
0.155 |
0,154 |
0,154 |
0,293 |
0,293 |
0,308 |
|
2 1/2 |
0,181 |
0,208 |
0,208 |
0,208 |
0,385 |
0,385 |
0,403 |
|
3 |
0,2 |
0,26 |
0,267 |
0,267 |
0,367 |
0,403 |
0,539 |
|
4 |
0.33 |
0.35 |
0,349 |
0,45 |
0,532 |
0,569 |
0,757 |
|
5 |
0,355 |
0,485 |
0,478 |
0,693 |
0,744 |
0,813 |
1,038 |
|
6 |
0,4 |
0.635 |
0,619 |
0,781 |
0,987 |
0,965 |
1,312 |
|
8 |
0.52 |
0.801 |
0,838 |
1 |
1,493 |
1,418 |
1,846 |
|
10 |
0,722 |
0,98 |
1,055 |
1,573 |
2,135 |
2,135 |
2,757 |
|
12 |
1,12 |
1,287 |
1,346 |
1,9 |
2,708 |
3,082 |
3,591 |
|
14 |
1,35 |
1,893 |
1,912 |
2,069 |
2,79 |
3,831 |
// |
|
16 |
1,73 |
2,177 |
2,256 |
2,8 |
3,152 |
4,573 |
// |
|
18 |
1,66 |
2,561 |
2,665 |
3,05 |
3,755 |
5,238 |
// |
|
20 |
1.95 |
2,947 |
2,993 |
3,766 |
4,3 |
5,709 |
// |
|
24 |
2,5 |
3,919 |
4,007 |
4,585 |
5,87 |
7,948 |
// |
Spiral Wound Gasket with Inner and Outer Ring weight chart – SS Outer ring
|
316/FG/316/316 (weights in grams) |
||||||
|
DN |
150 |
300 |
600 |
900 |
1500 |
2500 |
|
1/2 |
35 |
49 |
49 |
66 |
66 |
82 |
|
3/4 |
49 |
70 |
70 |
78 |
78 |
92 |
|
1 |
50 |
80 |
76 |
95 |
95 |
110 |
|
1 1/4 |
71 |
89 |
89 |
108 |
108 |
165 |
|
1 1/2 |
85 |
112 |
112 |
130 |
130 |
202 |
|
2 |
128 |
153 |
153 |
290 |
290 |
310 |
|
2 1/2 |
190 |
210 |
210 |
386 |
386 |
407 |
|
3 |
195 |
250 |
250 |
360 |
360 |
555 |
|
4 |
315 |
340 |
420 |
525 |
525 |
525 |
|
5 |
335 |
500 |
685 |
742 |
800 |
1050 |
|
6 |
390 |
615 |
670 |
978 |
941 |
1325 |
|
8 |
450 |
760 |
950 |
1420 |
1400 |
1870 |
|
10 |
670 |
890 |
1300 |
1880 |
1930 |
2600 |
|
12 |
1080 |
1208 |
1710 |
2727 |
3140 |
3665 |
|
14 |
1255 |
1860 |
1980 |
2790 |
4000 |
III |
|
16 |
1590 |
2085 |
2665 |
3145 |
4675 |
/// |
|
18 |
1340 |
2350 |
2840 |
3640 |
5290 |
III |
|
20 |
1620 |
2720 |
3585 |
4185 |
5760 |
/// |
|
24 |
2060 |
3635 |
3735 |
4380 |
5900 |
/// |
To the engineers, the maintenance personnel and the procurement specialists, a proper knowledge of the spiral wound gasket with the outer ring weight chart in mm and kg is crucial in the correct planning of materials and compatibility of the system. Being aware of the approximate weight of the gasket according to its size, filler type and the outer ring material can make the implementation of the project faster, cost-effective and reliably sealed in practice with pressure vessels, heat exchangers and vital assemblies of flanges.
In addition to the estimation, gasket weight data have a direct impact on the installation strategy as well as on the safety of the operation. Special handling arrangements might be necessary with heavier gaskets, and a good weight record is important when making correct calculations of flange loading and alignment. Industries can reduce errors during installation, prevent overloading equipment and ensure constant sealing reliability in harsh conditions such as oil and gas, power plants and chemical process plants by using standardized weight charts.
